Description
ACE FMC-150-Hyd-206 150 Series High Performance Pump
Mfr Part #: FMC-150-HYD-206
Stocking Type: Purchased inc. Raw Material
Brand: Ace Pumps
Type: Hydraulic-Driven Centrifugal Pumps
The FMC-150-HYD-206 Centrifugal Pump from Ace Pumps is designed to provide mounting versatility, customized performance, and easy maintenance. Many original Ace hydraulic motor driven pumps are still operating today after 30 years of service.
FEATURES
• Designed to provide high pressures and large volumes for applications with large tanks and longer spray booms
• Equipped with a stainless steel shaft and wear ring for corrosion resistance
• 206 hydraulic motor allows up to 7 GPM and fits virtually all tractor hydraulic systems
• Self-priming
• Can be mounted in many different places as location not tied to the PTO or engine drive shaft
• Equipped with easily replaceable FKM mechanical seals
• Built-in needle valve allows bypass of up to 9 GPM excess hydraulic fluid (in open centre systems)
• 1-1/2" NPT inlet and 1-1/4" NPT outlet
ADDITIONAL NOTES
• Recommended for pressure compensating closed centre, load sensing/pressure flow compensating closed centre, or open centre (up to 16 GPM with needle valve bypass) hydraulic systems.
FEATURES
• Designed to provide high pressures and large volumes for applications with large tanks and longer spray booms
• Equipped with a stainless steel shaft and wear ring for corrosion resistance
• 206 hydraulic motor allows up to 7 GPM and fits virtually all tractor hydraulic systems
• Self-priming
• Can be mounted in many different places as location not tied to the PTO or engine drive shaft
• Equipped with easily replaceable FKM mechanical seals
• Built-in needle valve allows bypass of up to 9 GPM excess hydraulic fluid (in open centre systems)
• 1-1/2" NPT inlet and 1-1/4" NPT outlet
ADDITIONAL NOTES
• Recommended for pressure compensating closed centre, load sensing/pressure flow compensating closed centre, or open centre (up to 16 GPM with needle valve bypass) hydraulic systems.
