Description
The NX25-DDC Continuous Duty fuel transfer series allows users to fuel all day with less downtime. The NX25’s robust variable speed motor actively adjusts its speed for optimal performance and produces a true 25GPM flow rate at the nozzle. It reduces long-term damage on wetted components while also improving suction lift. Its low-profile, lightweight construction reduces installation time. Intelligent audible tones simplify the troubleshooting process by informing users when and where attention is needed. Its rugged powder-coated paint stands the test of time against even the toughest environmental factors.
Features:
- Unmatched Performance — Pumps 25% faster, eliminating hours of costly driver downtime while filling up equipment
- Continuous Operation — brushless variable speed motor transfers fuel all day without overheating, extending pump life and eliminating driver downtime
- Flexible Power Input — dual voltage design allows you to power from 12-24V DC batteries without worrying of burning up the motor
- Energy Efficient — Consumes up to 45% less electricity, slashing operating costs and boosting efficiency
- Ultra-Lightweight — pump weighs 60% less at only 25 pounds, making installation faster and strain free
- Reduced Maintenance Costs — 75% reduction in common field repair costs through patented design and robust construction
- Powder-Coated Exterior — thick powder-coated exterior provides elite protection from corrosion and tough environmental conditions
- Limited Lifetime Warranty — we stand behind our product with an industry-leading Limited Lifetime Warranty to protect your purchase and your business
- Fluid Compatibility — designed for daily use with diesel, gasoline, ethanol blends up to E15, kerosene, mineral spirits, methanol up to 15%, and biodiesel blends up to B20
You work through all kinds of conditions, so why shouldn’t your fuel transfer pump? Fill-Rite Company has set the standard for reliable fuel transfer pumps, meters, and accessories. Our customers recognize Fill-Rite for its durability and years of elite performance in the field. Proudly made in the USA with global materials, Fill-Rite equipment is constructed with heavy-duty materials to withstand rugged everyday use, extreme weather exposure, and both on and off-road applications. Fill-Rite is supported by a wide network of distributors and retailers, ensuring you will always be able to find replacement parts and rebuild kits for your fuel transfer equipment.
Performance:
| Max Flowrate | 25 GPM / 94 LPM |
|---|---|
| Power Type | 12V/24V DC |
| Compatible Fluids | Diesel, Kerosene, Biodiesel up to B20, Gasoline up to E15, Mineral Spirits |
| Inlet Size / Connection / Thread | 1 " / Female / NPT |
| Outlet Size / Connection / Thread | 1 " / Female / NPT |
| Mounting Size / Thread / Type | -- / -- / Foot Mount |
| Duty Cycle (min) | Continuous Duty |
| Power Source | Electrical |
| Motor Power (HP) | 0.33 |
| Max Current (A) | 30 A |
| Thermal Protection Switch | -- |
| Self Priming | -- |
| Suction Lift (ft.) | 12 ' |
| Dry Vacuum (in. Hg) | 11 |
| Operating Temperature Range (°F) | -- |
| Discharge Head (ft) | 48 ' |
| Strainer Mesh Size (Micron) | 20 x 20 x .008” |
| Max Operating Pressure (PSI) | 25 |
| Viscosity Range (cSt) | -- |
| Fuse Size (A) | -- |
| Additional Accessories | -- |
|---|---|
| Static Wire | -- |
| Ground Wire | Yes |
| Cable Length (ft) | 20 |
| Cable Gauge (GA) | 10 |
| Cable Connection | Alligator Clips |
| Filter | -- |
| Filter Function | -- |
| Suction Pipe | None |
| Suction Hose | None |
| Pipe Diameter (in.) | -- |
| Discharge Hose | 1” X 18’ Hose with Static Ground Wire |
| Nozzle | 1” Ultra Hi-Flow Automatic Diesel Nozzle (Red) |
| Swivel | -- |
| Swivel Type | -- |
| Swivel Thread Type | -- |
| Swivel Size | -- |
| Additional Accessories | -- |
